Product Information
| Complete Assembly Part # |
Elbow Only |
Mixer Only |
Elbow to Mixer Thread Spec |
Weld Metal Thickness |
Oxygen PSIG |
Acetylene PSIG |
Acetylene SCFH |
|---|---|---|---|---|---|---|---|
| TYPE4-000 | TYPE4E-000 | UM4-0 | 5/16”-27 (M,F) | Up to 1/32” | 5 | 5 | 1.5 |
| TYPE4-00 | TYPE4E-00 | UM4-0 | 5/16”-27 (M,F) | 1/64”-3/64” | 5 | 5 | 2.5 |
| TYPE4-0 | TYPE4E-0 | UM4-0 | 5/16”-27 (M,F) | 1/32”-5/64” | 5 | 5 | 4 |
| TYPE4-1 | TYPE4E-1 | UM4-1 | 5/16”-27 (M,F) | 3/64”-3/32” | 5 | 5 | 6 |
| TYPE4-2 | TYPE4E-2 | UM4-1 | 5/16”-27 (M,F) | 1/16”-1/8” | 5 | 5 | 10 |
| TYPE4-3 | TYPE4E-3 | UM4-3 | 3/8”-27 (M,F) | 1/8”-3/16” | 7 | 6 | 18 |
| TYPE4-4 | TYPE4E-4 | UM4-4 | 3/8”-27 (M,F) | 3/16”-1/4” | 10 | 7 | 28 |
| TYPE4-5 | TYPE4E-5 | UM4-5 | 7/16”-27 (M,F) | 1/4”-1/2” | 12 | 8 | 40 |
| TYPE4-6 | TYPE4E-6 | UM4-5 | 7/16”-27 (M,F) | 1/2”-3/4” | 14 | 9 | 52 |
| TYPE4-7 | TYPE4E-7 | UM4-7 | 7/16”-27 (M,F) | 3/4”-1-3/4” | 16 | 10 | 66 |
| TYPE4-8 | TYPE4E-8 | UM4-7 | 7/16”-27 (M,F) | 1-1/2”-2” | 19 | 12 | 82 |
