Product Information
| Complete Assembly Part # | Tip End Only | Mixer Only | Elbow to Mixer Thread Spec | Oxy-Fuel Acetylene Equal Pressure PSIG | Flow (SCFH) Each Gas |
|---|---|---|---|---|---|
| TYPE11H-5 | TYPE11TE-5 | UM43D | 7/16”-27 (M) | 7 | 35 |
| TYPE11H-6 | TYPE11TE-6 | UM43D | 7/16”-27 (M) | 8 | 40 |
| TYPE11H-7 | TYPE11TE-7 | UM43D | 7/16”-27 (M) | 10 | 50 |
| TYPE11H-8 | TYPE11TE-8 | UM43D | 7/16”-27 (M) | 12 | 60 |
| TYPE11H-10* | TYPE11TE-10 | UM43D-2 | 1/2”-27 (M) | 15 | 90 |
| TYPE11H-12* | TYPE11TE-12 | UM43D-2 | 1/2”-27 (M) | 15 | 150 |
*Use 3/8″ hose on larger tips for adequate gas flow.
