RUHS Series

Uniweld’s RUHS Station Regulator Series feature:

• Machined brass body
• Polished chrome bonnet
• Easy-to-read single scale 2″ gauges
• 2″ tri-layered reinforced neoprene diaphragm
• Mechanical stem type seat
• Delrin bushing for smooth flow adjustment
• Porous metal inlet filter (except CO2 models)
• Fine mesh filter screen between inlet and seat
• Pressure relief device for low pressure gauge protection only

**Different Pressure Scales & Inlet Connections Available Upon Request**



WARNING
Do Not Connect A Station Regulator To A Cylinder!

Product Information

Part # CGA Inlet Outlet Connection Delivery PSIG 2″ Replacement Gauges
RUHS8210 Oxygen CGA024

7/8″-14 (RH) (F)

“B” (RH) 9/16″-18 M 5-125 G4S; 200 PSI
RUHS8211 Acetylene CGA025

7/8″-14 (LH) F

“B” (LH) 9/16″-18 M 2-15 G2S; 30 PSI (RL)
RUHS8212 LPG & All Fuel Gases CGA034

7/8″-14 (LH) F

“B” (LH) 9/16″-18 M 2-40 G5S; 60 PSI
RUHS8213 Carbon Dioxide CGA034

7/8″-14 (RH) M

RH (F) 5/8″-18 5-125 G4S; 200 PSI
RUHS8214 Argon CGA034

7/8″-14 (RH) M

RH (F) 5/8″-18 5-125 G4S; 200 PSI
RUHS8215 Nitrogen CGA034

7/8″-14 (RH) M

RH (F) 5/8″-18 5-125 G4S; 200 PSI
