Mild Steel Alloys

Uniweld offers many types of welding alloys used for joining a wide variety of metals. When joining metals, the alloys being used should be similar, but not identical to the metal that is being joined. When joining dissimilar metals, the alloys will be different from one or both of the base metals.

Product Information

Part # Product Description Size
D67F4SC Uni-6011 SELECT 14″ 5 lb Package 3/32″
D67F5SC Uni-6011 SELECT 14″ 10 lb Package 3/32″
D67F8SC Uni-6011 SELECT 14″ 50 lb Package 3/32″
D67H4SC Uni-6011 SELECT 14″ 5 lb Package 1/8″
D67H5SC Uni-6011 SELECT 14″ 10 lb Package 1/8″
D67H8SC Uni-6011 SELECT 14″ 50 lb Package 1/8″
D67F8 Uni-6011 14″ 50 lb Package 3/32″
D67H8 Uni-6011 14″ 50 lb Package 1/8″
D67H8-HSC Uni-6011 14″ 50 lb Can 1/8″
D67J4SC Uni-6011 SELECT 14″ 5 lb Package 5/32″
D67J5SC Uni-6011 SELECT 14″ 10 lb Package 5/32″
D67J8SC Uni-6011 SELECT 14″ 50 lb Package 5/32″
D67J8 Uni-6011 14″ 50 lb Package 5/32″
D67J8-HSC Uni-6011 14″ 50 lb Can 5/32″
D67K8 Uni-6011 14″ 50 lb Package 3/16″
D67K8-HSC Uni-6011 14″ 50 lb Can 3/16″
D87F4SC Uni-6013 SELECT 14″ 5 lb Package 3/32″
D87F5SC Uni-6013 SELECT 14″ 10 lb Package 3/32″
D87F8SC Uni-6013 SELECT 14″ 50 lb Package 3/32″
D87H4SC Uni-6013 SELECT 14″ 5 lb Package 1/8″
D87H5SC Uni-6013 SELECT 14″ 10 lb Package 1/8″
D87H8SC Uni-6013 SELECT 14″ 50 lb Package 1/8″
D87J4SC Uni-6013 SELECT 14″ 5 lb Package 5/32″
D87J5SC Uni-6013 SELECT 14″ 10 lb Package 5/32″
D87F8 Uni-6013 14″ 50 lb Package 3/32″
D87H8 Uni-6013 14″ 50 lb Package 1/8″
DN7H4SC Uni-6022 SELECT 14″ 5 lb Package 1/8″
DN7H5SC Uni-6022 SELECT 14″ 10 lb Package 1/8″
DN7H8SC Uni-6022 SELECT 14″ 50 lb Package 1/8″
DN7J4SC Uni-6022 SELECT 14″ 5 lb Package 5/32″
DN7J5SC Uni-6022 SELECT 14″ 10 lb Package 5/32″
DN7J8SC Uni-6022 SELECT 14″ 50 lb Package 5/32″
D97F4SC Uni-7014 SELECT 14″ 5 lb Package 3/32″
D97F5SC Uni-7014 SELECT 14″ 10 lb Package 3/32″
D97F8SC Uni-7014 SELECT 14″ 50 lb Package 3/32″
D97H4SC Uni-7014 SELECT 14″ 5 lb Package 1/8″
D97H5SC Uni-7014 SELECT 14″ 10 lb Package 1/8″
D97H8SC Uni-7014 SELECT 14″ 50 lb Package 1/8″
D97J4SC Uni-7014 SELECT 14″ 5 lb Package 5/32″
D97J5SC Uni-7014 SELECT 14″ 10 lb Package 5/32″
D97F8 Uni-7014 14″ 50 lb Package 3/32″
D97H8 Uni-7014 14″ 50 lb Package 1/8″
DA7F4SC Uni-7018 SELECT 14″ 5 lb Can 3/32″
DA7F5SC Uni-7018 SELECT 14″ 10 lb Can 3/32″
DA7F8SC Uni-7018 SELECT 14″ 50 lb Can 3/32″
DA7H4SC Uni-7018 SELECT 14″ 5 lb Can 1/8″
DA7H5SC Uni-7018 SELECT 14″ 10 lb Can 1/8″
DA7H8SC Uni-7018 SELECT 14″ 50 lb Can 1/8″
DA7F8 Uni-7018 14″ 50 lb Can 3/32″
DA7H8 Uni-7018 14″ 50 lb Can 1/8″
DA7J4SC Uni-7018 SELECT 14″ 5 lb Can 5/32″
DA7J5SC Uni-7018 SELECT 14″ 10 lb Can 5/32″
DA7J8SC Uni-7018 SELECT 14″ 50 lb Can 5/32″
DA7J8 Uni-7018 14″ 50 lb Can 5/32″
DA7K8 Uni-7018 14″ 50 lb Can 3/16″
DA738 Uni-7018 14″ 50 lb Can 1/4″
DB7F4SC Uni-7018AC SELECT 14″ 5 lb Can 3/32″
DB7F5SC Uni-7018AC SELECT 14″ 10 lb Can 3/32″
DB7F8SC Uni-7018AC SELECT 14″ 50 lb Can 3/32″
DB7H4SC Uni-7018AC SELECT 14″ 5 lb Can 1/8″
DB7H5SC Uni-7018AC SELECT 14″ 10 lb Can 1/8″
DB7H8SC Uni-7018AC SELECT 14″ 50 lb Can 1/8″
DB7J4SC Uni-7018AC SELECT 14″ 5 lb Can 5/32″
DB7J5SC Uni-7018AC SELECT 14″ 10 lb Can 5/32″
DB7H8 Uni-7018AC 14″ 50 lb Can 1/8″
DC7H8 Uni-7024 14″ 50 lb Package 1/8″
DC7J8 Uni-7024 14″ 50 lb Package 5/32″
DC7K8 Uni-7024 14″ 50 lb Package 3/16″
DC738 Uni-7024 14″ 50 lb Package 1/4″
DV7H4SC Unipipe-6 SELECT 14″ 5 lb Can 1/8″
DV7H5SC Unipipe-6 SELECT 14″ 10 lb Can 1/8″
DV7H8SC Unipipe-6 SELECT 14″ 50 lb Can 1/8″
DV7J4SC Unipipe-6 SELECT 14″ 5 lb Can 5/32″
DV7J5SC Unipipe-6 SELECT 14″ 10 lb Can 5/32″
DV7J8SC Unipipe-6 SELECT 14″ 50 lb Can 5/32″
DV7H8 Unipipe-6 14″ 50 lb Can 1/8″
DV7J8 Unipipe-6 14″ 50 lb Can 5/32″
DV7K8 Unipipe-6 14″ 60 lb Can 3/16″
DEAD5 Steel 45 36″ 10 lb Pakcage 1/16″
DEAF5 Steel 45 36″ 10 lb Pakcage 3/32″
DEAH5 Steel 45 36″ 10 lb Pakcage 1/8″
DFAD5 Steel 60 36″ 10 lb Pakcage 1/16″
DFAF5 Steel 60 36″ 10 lb Pakcage 3/32″
DFAH5 Steel 60 36″ 10 lb Pakcage 1/8″
DGAD5 Steel TIG 70S2 36″ 10 lb Pakcage 1/16″
DGAF5 Steel TIG 70S2 36″ 10 lb Pakcage 3/32″
DGAH5 Steel TIG 70S2 36″ 10 lb Pakcage 1/8″
DJ4Z2 Steel MIG 70S6 2 lb Spool .023″
DJ4ZA Steel MIG 70S6 11 lb Spool .023″
DJ4ZW Steel MIG 70S6 33 lb Spool .023″
DJ4I2 Steel MIG 70S6 2 lb Spool .030″
DJ4IA Steel MIG 70S6 11 lb Spool .030″
DJ4P2 Steel MIG 70S6 2 lb Spool .035″
DJ4PA Steel MIG 70S6 11 lb Spool .035″
DJ4PZ Steel MIG 70S6 44 lb Spool .035″
DJFIW Steel MIG 70S6 Precision Wound 33 lb Spool .030″
DJFPW Steel MIG 70S6 Precision Wound 33 lb Spool .035″
DJFRW Steel MIG 70S6 Precision Wound 33 lb Spool .045″
DJ4RZ Steel MIG 70S6 Precision Wound 44 lb Spool .045″
DJAD5 Steel TIG 70S6 36″ 10 lb Pakcage 1/6″
DJAF5 Steel TIG 70S6 36″ 10 lb Pakcage 3/32″
DJAH5 Steel TIG 70S6 36″ 10 lb Pakcage 3/32″
DT4I2 71TGS 2 lb Spool .030″
DT4I5 71TGS 10 lb Spool .030″
DT4P2 71TGS 2 lb Spool .035″
DT4P5 71TGS 10 lb Spool .035″

Additional information

Uni-6011

• Used on a wide range of base metals.

• Usable in all positions.

• Applications include: Tanks (both, plain and galvanized), pipe welding, steel casting repairs, machinery parts and structural fabrication.

• Fast freezing deposit for the vertical up progression used in piping in the horizontal position.

• Works well with AC power source.

Uni-6013

• Used on all types of mild steel fabrication requiring ease of operation and good appearance with either AC or DC straight polarity.

• Works well with poor fit up.

• Smooth, flat bead appearance .

• Easy slag removal

Note: 5/32" 14" 50 lb Package available (D87J8SC and D87J8).

Uni-6022

• A fluid electrode that is reliable for roof decking and down hill welding. Designed for welding roof decking to support beams with burn-through spot welds.

• Rapid downhill welding when joining light gauge materials, including sheet metal

Uni-7014

• Suitable for most types of mild steel fabrication and/or iron work. used in applications where a very smooth appearance is important, including machine bases, frames and heavy sheet metal.

• AC/DC, either polarity

Notes: 5/32" 14" 50 lb Package available (D97J8SC and D97J8)

Uni-7018

• A low Hydrogen content electrode used on Carbon and medium textile steels, especially under conditions of restraint. Used in construction grades of steel for ship building, pipelines, boiler plate, cast steel and for machine screw parts

• X-ray quality welds

• High impact fracture resistance

Uni-7018AC

• A low Hydrogen electrode for low, medium and high carbon steels and high strength low alloy steels. Works well for skip or track welds in utility and job shops where single phase 230V AC welders are used

• Excellent restrike characteristics

Notes: 5/32" 14" 50 lb Can available ( DB7J8SC)

Uni-7024

• A high speed Iron powder mild steel electrode used for plate fabrication, earth moving equipment, mining machinery, structural steel, railroad cars, agricultural machinery and general maintenance work.

• Maximum deposition rate

• Self removing type slag

• use with drag technique

Unipipe-6

• A quick staring, all-position cellulosic mild steel electrode exhibiting superior arc stability, superior arc drive (penetration), tight slag and excellent wash-in.

• General purpose fabrication, construction, shipbuilding and maintenance welding applications

• Out-of-position X-ray welds

• Vertical and overhead plate welding

Steel 45

• A general purpose, low carbon steel rod used for oxyacetylene welding of most common grades of steel

• Good ductility and machinability

Steel 60

• A high strength steel welding rod used for welding of carbon steel pipes in power plants and other conditions of severe service

• Oxyacetylene torch applications

• Meets all codes for grade B steels

• Responds to heat treatment, flame hardening and cyaniding

Steel TIG 70S2

• Triple deoxidized steel welding wire used for single pass or mulitpass welding on all grades of carbon steel

• Especially suited for dirty or rusted surfaces

• Short-arc welding

Steel MIG 70S6/ Steel TIG 70S6

• High speed mild steel welding wire with high Silicone and Manganese content. Used primarily for single pass welding.

• High deoxidizer content for welding scaled and rusty plates

• Excellent fluidity

• Smooth bead appearance

• Quiet, stable arc

71TGS

• An all-position, general purpose, self-shielding, flux cored welding wire for single pass applications. Used by fencing contractors, sheet metal shops, sign erectors and ranchers for outdoor applications with no gas required.

• Used with portable 110V input welding machine

• Requires no shielding has

• High deposition efficiency

• Easy slag removal

Uni-308L-16

• An extra low carbon stainless steel welding electrode used to weld Types 304L and 347. The weld deposit, with controlled Ferrite, provides notch toughness and increased crack resistance.

• Minimizes formation of chromium carbides

• AC/DC reverse polarity

Uni-309L-16

• Used primarily for joining stainless steels to themselves or to carbon or low alloy steels. Also used for welding dissimilar joints, that undergo heat treatment

• Increased resistance to intergranular corrosion

• Reduced carbon levels
